EXS82-W L30960-N6200 Global MTC Module LTE-M NB-IoT 2G Teli Cinterion Wireless IoT Module is driving LTE evolution to 5G, enabling Low Power Wide Area (LPWA) connectivity for billions of new indu
| Place of Origin | Vietnam |
|---|---|
| Brand Name | Telit Cinterion |
| Model Number | EXS82-W L30960-N6200 |
| Minimum Order Quantity | 500 |
| Price | $11.20 /pieces |
| Payment Terms | T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Product Description
EXS82
Global MTC Module (LTE Cat M/NB/2G)
Telit Cinterion EXS82-W Wireless IoT Module is driving LTE evolution to 5G, enabling Low Power Wide Area (LPWA) connectivity for billions of new industrial applications.
- LTE-M NB-IoT 2G
- Incremental FOTA Updates
- Embedded Processing
Product Features
- FDD-LTE Bands 1, 2, 3, 4, 5, 8, 12, 13, 18, 19, 20, 25, 26, 27, 28, 66, 71, 85.
- Quad-Band GSM: 850, 900, 1800 and 1900 MHz (*)
- Integrated GNSS support (GPS/BeiDou/Galileo/GLONASS)
- Compatible with Cinterion® Industrial module footprint
- SIM Application Toolkit with BIP
- Control via standardized commands (Hayes, TS 27.007 and 27.005) and Cinterion® AT commands
- Embedded IPv4 and IPv6 TCP/IP stack access via AT command, provides: TCP/UDP Client, UDP Endpoint, TCP Listener, HTTP client, FTP client, MQTT client, NTP service,
CoAP Client - Secure Connection with TLS/DTLS
- Compliant with GSMA SGP.22 Remote SIM Provisioning (RSP) standard
- Validated against Telit Cinterion NExT SGP.22 eSIMs
Specifications
- 3GPP Rel.14 Compliant Protocol
- LTE Power Class 5 (20 dBm)
- LTE Cat.M1 DL: max. 300 kbps, UL: max. 1.1 Mbps
- LTE Cat.NB1 DL: max. 27 kbps, UL: max. 63 kbps
- LTE Cat.NB2 DL: max.124 kbps, UL: max. 158 kbps
- E/GPRS Class 10 *)
- SMS support (via NAS, via GSM)
*EXS 82 only
Certifications
- RED, GCF, CE, FCC, PTCRB, IC, UL, CCC, IFETEL, UKCA,
- Anatel, JATE, TELEC,AT&T (Firstnet), Verizon, Telstra, NTT Docomo, KDDI, T-Mobile (-X)
Dimension:
27.6 x 18.8 x 2.3 mm
Supply voltage range:
2.6-4.8 V
Weight:
approx. 2.5 g
Operating temperature-40°C to +90°C
Interfaces
- Pads for primary LTE antenna and GNSS antenna
- 2 high-speed serial interface
- USB 2.0 interface
- UICC and U/SIM card interface 1.8V
- SPI, I2C, PWM signal line
- ADC, GPIO
- eSIM Remote Provisioning** (IoT Connectivity Activation)
- Firmware updatable via interface and Over the Air (OTA) / incremental FOTA
- LWM2M support with Cinterion IoT Suite
- eDRx: 81.92s <0.77mA, and PSM 4.5µA
- Advanced Security
- Embedded Processing
** included in future firmware version
- Driver for Windows® 7 / Windows® 8 / Windows 10
- Driver for Linux
